OKP662GH
1160566
Specification
FEATURES
| Accessories Pipe | Air flaps Yes | Delay Yes |
| Maximum time of delay 15 ' | Montage template Yes | Panel - language version Pictograms |
| Pipe Yes | Protection class of electric shock I_Class | Type of work Extraction/Recirculation |
Equipment
| Carbon filter(s) included Yes | Number of carbon filters 1 | Number of grease filters 2 |
| Number of layers in grease filter 5 | Number of speed 3 | Type of control Sensor |
| Type of display LCD | Type of grease filters Aluminium frame | Carbon filter type FWP 03 |
Technical data
| Air flow at 1 speed - extractor by EN 61591 424 m3/h | Air flow at 2 speed - extractor by EN 61591 545 m3/h | Air flow at 3 speed - extractor by EN 61591 650 m3/h | |||||||||||||||||||||||||||||
| Air Flow at Maximum Speed in Normal Use [Intensive or Boost Excluded] 650 m3/h | Air Flow at Minimum Speed in Normal Use 424 m3/h | Air Flow Rate at Best Efficiency Point - Q BEP 347.2 m3/h | |||||||||||||||||||||||||||||
| Air Pressure at Best Efficiency Point P BEP 340 Pa | Annual energy consumption 67.8 kWh | Average Illumination of the Lighting System on the Cooking Surface - E middle 78 lux | |||||||||||||||||||||||||||||
| Container qty 40'HQ 435 | Control panel on one side/two sides One side | Country of Origin on Rating Label Made in PRC | |||||||||||||||||||||||||||||
| Dimensions of grease filter 278 x 211 mm | Display color Red | Distance from light cover to wall 6 mm | |||||||||||||||||||||||||||||
| Distance to electric hob 450 mm | Distance to gas hob 650 mm | Electric Power Input at Best Efficiency Point - W BEP 150.2 W | |||||||||||||||||||||||||||||
| Fluid Dynamic Efficiency - FDE hood 21.8 | Fluid Dynamic Efficiency Class C | Grease Filtering Efficiency - GFE hood 82.6 % | |||||||||||||||||||||||||||||
| Grease Filtering Efficiency Class C | Internal/external motor Internal | Main lighting colour temperature [K] 6500 | Lighting Efficiency - LE hood 28.9 lux/W | Lighting Efficiency Class A | Lighting Efficiency Class A | Maximum Possible Air Flow 650 m3/h | Motor unit rated power 230 W | Motor type/model E series | Net depth 500 mm | Net height max 930 mm | Net height min 550 mm | Net weight 14 kg | Net width 600 mm | Noise level at 1 speed - extractor by EN 60704-2-13 57 dB | Noise level at 2 speed - extractor by EN 60704-2-13 63 dB | Noise level at 3 speed - extractor by EN 60704-2-13 68 dB | Nominal Power of the Lighting System - W L 2.7 W | Number of motor units 1 | Number units of main lighting 2 | Air exhaust diameter 150 mm | Type of plug or cable Euro plug | Power Consumption in Standby Mode - Ps 0.46 W | Power cabel length 120 cm | Power rating 234 W | Power Supply Voltage 230V | Power unit of main lighting 2 W | Sound Power Emission at Maximum Speed Available in Normal Use [Intensive or Boost Excluded] 68 dB | Sound Power Emission at Minimum Speed Available in Normal Use 57 dB | Noise level 68 dB | Time Increase Factor - f 1.2 | Type of main lighting LED - other |
